Dino Paoli S.r.l. Via G. Dorso, 5 - 42124 Reggio Emilia - Italy Tel. +39 0522 364511 - Fax + 39 0522 304864 www.paoli.net sales@paoli.net

The information, images and/or data contained in this catalogue are copyrighted by Dino Paoli S.r.l. All other logos, products and company names mentioned in the Dino Paoli S.r.l. General Catalogue are trademarks of their respective owners. Models, specifications, colors and codes are subject to change without prior notice due to continuous improvements. Thank you for your interest in our products. Le informazioni, le immagini e/o i dati contenuti in questo catalogo sono protetti da copyright Dino Paoli S.r.l. Tutti gli altri loghi, prodotti e nomi di società menzionati nel Catalogo...

TECHNOLOGICAL INNOVATION AT YOUR FINGERTIPS INNOVAZIONE TECNOLOGICA A PORTATA DI MANO For more than 50 years DINO PAOLI SRL has been manufacturing professional impact wrenches, with the aim of supplying to every customer - from tyre changers to mechanics, from the workshop to the industry - the best available technologies. Strong, reliable and long-lasting products are developed building on Paoli’s experience. The incessant research and the company know-how made possibile the realization of impact wrenches dedicated to the industry field, infrastructures, industrial maintenance, railway,...

Dino Paoli S.r.l. was born in 1968 and it has specialized in the production of impact wrenches used in workshops for commercial vehicles and standard road cars. Dino Paoli S.r.l. starts producing impact wrenches with air exhaust trough the handle: noise and fine dusts are reduced. Paoli ecological trolleys arrive on the market. Dino Paoli S.r.l. introduces a new range of impact wrenches following the ATEX certification, dedicated to explosive environments and industrial mainenance. La Dino Paoli S.r.l. nasce nel 1968 e si specializza nella produzione di avvitatori utilizzati nelle officine...

PAOLI WORLDWIDE PRESENCE SUPER FORMULA PAOLI MOTORSPORT PRESENCE + 30% YOY (YEAR OVER YEAR)

HAMMER MECHANISM TYPES TIPOLOGIE DI MECCANISMI AD IMPULSO PIN-CLUTCH SYSTEM IN OIL BATH The 3-jaw system produces a single impact for each cycle on all 3-jaws and a high torque value. This system also gives low vibration levels. This type is suggested mainly for tightening hard joints. m Advantages: power reliability readiness The pin-clutch system produces a single impact for each cycle. The strokes are made by two pins which are pitched directly on the shaft. This creates a balanced impulse and a lower vibration level compared to the other systems. m Advantages: low vibrations low...

TIPOLOGIE DI MECCANISMI AD IMPULSO HAMMER MECHANISM TYPES TWIN-HAMMER SYSTEM JUMBO SYSTEM The twin-hammer system produces a double impact for each cycle on both sides of the shaft. The use of 2 opposite hammers allows to obtain a balanced impact. It is mainly used for 1/2 inch impact wrenches. m Advantages: cost effective durability due to lower effort The jumbo system produces a single impact for each cycle. This system is mainly used for 1/2 inch small impact wrenches. This hammer mechanism is extremely strong and performing. m Advantages: speediness performances The 2-jaw system produces...

GAMMA A COPPIA CONTROLLATA MOBILE WORKING STATIONS POSTAZIONI DI LAVORO MOBILE 120 MWS-Suspension Naked 122 MWS-Suspension Basic 124 MWS-Suspension Complete 126 MWS-Suspension Full Optional 176 DPLIFT 60/22 177 DPLIFT 100/40 185 Smart Lift 186 Axle Stands and Trolleys ALIMENTAZIONE ARIA COMPRESSA 198 Turning Connectors 201 Power Regulators 94 Battery Nutrunners 96 Nutrunners' Accessories GAMMA ELETTRO-IDRAULICA CON LEVA MECCANICA 166 DPLIFT 80 Q 167 DPLIFT 100 QL 167 DPLIFT 120 Q 167 DPLIFT 200 Q 173 DPLIFT 660 S UTENSILI PNEUMATICI TORQUE CONTROL RANGE ELECTRO-HYDRAULIC RANGE WHIT...

IMPACT WRENCHES AVVITATORI TORQUE CONTROL RANGE ATEX IMPACT WRENCHES MOBILE WORKING STATIONS ELECTRO-HYDRAULIC RANGE UTENSILI PNEUMATICI AVVITATORI A BATTERIA GAMMA A COPPIA CONTROLLATA AVVITATORI ATEX POSTAZIONI DI LAVORO MOBILE GAMMA ELETTRO-IDRAULICA ELECTRO-HYDRAULIC RANGE WHIT MECHANICAL LEVER GAMMA ELETTRO-IDRAULICA PRODUCT CARE SOLLEVATORI DP LIFT ALIMENTAZIONE ARIA COMPRESSA ACCESSORI ASSISTENZA TECNICA DOMANDE FREQUENTI

IMPACT WRENCHES Dino Paoli impact wrenches are iconic. The Motorsport experience gives birth to models always able to provide the users with the best available technology. Dino Paoli, from its Italian headquarters, designs and sells daily and heavy duty impact wrenches: a complete range conceived to meet the needs of professionals working in tyre and mechanical workshops, as well as in the industrial sectors. Paoli impact wrenches are widely used for the following applications: • Automotive field: - cars - commercial and light industrial vehicles - trucks, buses and other heavy vehicles •...

IMPACT WRENCHES AVVITATORI

PAOLI IMPACT WRENCHES APPLICATIONS 3/8” BEST FOR APPLICAZIONI Mechanical workshops Officine meccaniche Cars, van, suv tyreshops Gommisti vetture, van, suv Commercial vehicles tyreshops Gommisti veicoli commerciali Heavy vehicles tyreshops Gommisti mezzi pesanti Industrial assembly Montaggi industriali Usable with Paoli Mobile Working Station Utilizzabile con Postazione di Lavoro Mobile Paoli Infrastructures Infrastrutture Construction site and shipyard Cantieri e costruzioni navali Railways applications Applicazioni ferroviarie APPLICAZIONI DEGLI AVVITATORI PAOLI 3/4”

PAOLI IMPACT WRENCHES APPLICATIONS APPLICAZIONI DEGLI AVVITATORI PAOLI 1” BEST FOR APPLICAZIONI Mechanical workshops Officine meccaniche Cars, van, suv tyreshops Gommisti vetture, van, suv Commercial vehicles Gommisti veicoli commerciali Heavy vehicles Gommisti mezzi pesanti Industrial assembly Montaggi industriali Usable with Paoli Mobile Working Stations Utilizzabile con Postazione di Lavoro Mobile Paoli Infrastructures Infrastrutture Construction site and shipyard Cantieri e costruzioni navali Railways applications Applicazioni ferroviarie
